RX27
| Resistor Type | Power(W) | Resistance Range(Ω) | Dimension(mm) | ||||
| A/B | C | ∅ | h | ||||
| RX27-1-2 | RX27-2-2 | 2 | 0.15-200 | 6.4±1 | 17.5±1.2 | 0.8 | 1.5 |
| RX27-1-3 | RX27-2-3 | 3 | 0.2-390 | 8±1 | 22±1.5 | 0.8 | 1.5 |
| RX27-1-5 | RX27-2-5 | 5 | 0.24-680 | 9.5±1 | 22±1.5 | 0.8 | 1.5 |
| RX27-1-7 | RX27-2-7 | 7 | 0.33-1500 | 9.5±1 | 35±1.5 | 0.8 | 3 |
| RX27-1-10 | RX27-2-10 | 10 | 0.51-2000 | 9.5±1 | 48±1.5 | 0.8 | 3 |
| RX27-1-15 | 15 | 1-2400 | 12.5±1.2 | 48±1.5 | 1 | ||
| RX27-1-20 | 20 | 1-3000 | 12.5±1.2 | 63.5±2 | 1 | ||
